6mm 200m Orange Glider Tow Ropes UHMWPE Rope 3260kg Winch Line
Material: UHMWPE
GIRO MAX is high quality UHMWPE rope product used for most demanding mooring, towing and lifting applications. The advanced equipment from Germany and Denmark and the mature technology in rope manufacturig account for its high quality and stability.
GIRO MAX ropes is your optimal choice for diversified mooring applications for its properties of high strength, excellent abrasion resistance, high strength-to-weight ratio, exremenly low enlongation and superior flex fatigue resistance.
| DIA | CIR | Linear Density | MBL(KN) |
| MM | INCH | Ktex | Unspliced | Spliced |
| 6 | 3/4 | 23 | 46.5 | 42 |
| 8 | 1 | 37 | 73 | 66 |
| 10 | 1-1/4 | 56 | 105 | 95 |
| 12 | 1-1/2 | 79 | 145 | 131 |
| 14 | 1-3/4 | 106 | 193 | 174 |
| 16 | 2 | 151 | 260 | 235 |
| 18 | 2-1/4 | 190 | 310 | 283 |
| 20 | 2-1/2 | 232 | 380 | 340 |
| 22 | 2-3/4 | 281 | 450 | 400 |
| 24 | 3 | 331 | 520 | 470 |
| 26 | 3-1/4 | 384 | 600 | 540 |
| 28 | 3-1/2 | 445 | 680 | 610 |
| 30 | 3-3/4 | 506 | 770 | 690 |
| 32 | 4 | 575 | 870 | 780 |
| 34 | 4-1/4 | 648 | 960 | 860 |
| 36 | 4-1/2 | 720 | 1040 | 940 |
| 38 | 4-3/4 | 798 | 1160 | 1040 |
| 40 | 5 | 881 | 1260 | 1130 |
| 44 | 5-1/2 | 1060 | 1460 | 1310 |
| 48 | 6 | 1250 | 1700 | 1530 |
| 52 | 6-1/2 | 1460 | 1970 | 1770 |
| 56 | 7 | 1690 | 2260 | 2030 |
| 60 | 7-1/2 | 1930 | 2530 | 2280 |
| 64 | 8 | 2200 | 2840 | 2560 |
| 68 | 8-1/2 | 2480 | 3170 | 2850 |
| 72 | 9 | 2780 | 3520 | 3170 |
| 76 | 9-1/2 | 3090 | 3890 | 3500 |
| 80 | 10 | 3430 | 4300 | 3870 |
| 88 | 11 | 4170 | 5200 | 4680 |
| 96 | 12 | 4970 | 6180 | 5560 |
Main Performance
| Material | UHMWPE |
| Construction | 12 strand braided |
| Treatment | Marine finish,Offshore |
| Standard Color | Yellow(also available by special order in red,green,blue,orange and so on) |
| Approx.Spec.Density | 0.975 Floating |
| Melting Point | 145℃ |
| Vabrasion Resistance | Excellent |
| U.V.resistance | Good |
| Temperature resistance | 70℃ max continuous |
| Dry & wet conditions | wet strength equala dry strength |
| Range of use | fishing,off-shore installation,mooring |
| Coil length | 220m (length can be customized) |
| Spliced strength | ±10% |
| Weight and lengthtolerance | ±5% |
| MBL=Minimum Breaking Load | Conform Iso 2307 |
| Other sizes | Available upon request |
Hot Sale Display
Workshop Show
Certifications
Packaging, Payment & Shipping
Why US
1. 100% manufacturer
2. Best material selection
All our goods are by use of best or suitable materials from the best suppliers.
3. Good service
We definitely produce all goods by oursevers. It is the stop service from wiredrawing, ring twisting, rope
twisting/braiding, QC, packing.
4. After sales service provided
Besides, after sales service is necessary for more understanding for your needs. We do keep a close concern.
5. Flexible quantity
If your bid is ok for both parties, We could accept any quantity.
Of course, we like the big quantity, Because we have ability for big order
6. Good relation on forwarders
Whave good relation on our forwarders,
Because we could place lots of orders to them
So your cargo can be transported by air or by sea on time
